38113 1500m Fibre Optic DVI-D Single Link Extender

Download product sheet

This fiber-optic extender allows you to transmit a DVI-D video signal up to 500 meters using a multimode duplex LC cable (50/125 µm) or up to 1,500 meters using a single-mode cable (9/125 µm).

Buy this product online

Search Google Shopping

Product details

Key features

Extends DVI-D signals at distances of up to 1500m using a single fibre optic cable (not included)
Supports HDTV resolutions up to 1920x1200@60Hz / 1080p@60Hz
6Gbps Total Bandwidth over Single 2-core Fibre Optic Cable Link
TAA compliant
2 year warranty

Specifications

AV Interface

DVI-D
Interface Standard

DVI-D 2.0 (Single Link)
Supported Bandwidth

4.95Gbps
Maximum Distance

500m (1640.4ft) - 1x LC Duplex (50/125µm); 1500m (4921.2ft) - 1x LC Duplex (9/125µm)
Maximum Resolution

1920x1200@60Hz
Transmission Medium

1 x Duplex LC (50/125µm / 9/125µm)
Laser Class (only for Fibre)

1
Wavelength (only for Fibre)

1310/1550nm
Special Features

Self-EDID learning
Transmitter Input

DVI-D (Male)
Transmitter Output

Duplex LC (Female)
Receiver Input

Duplex LC (Female)
Receiver Ouput

DVI-D (Male)
Power

3.5/1.35mm DC socket
Dimensions WxDxH

40x70x15mm (1.57x2.76x0.59in) per unit
Housing Material

Metal
Net Weight

0.1kg (0.22lb) per unit
Operating Temperature

0°C - 50°C (32°F - 122°F)
Storage Temperature

-20°C - 65°C (-4°F - 149°F)
Humidity

10 - 75% RH (non-condensing)
Power Requirements

5VDC <400mA per unit
Colour

Silver
Unit

Transmitter and Receiver
