70436 2 Port Automatic Optical Audio Switch
Download product sheetThe Lindy 2 Port Automatic Optical Audio Switch allows users to connect two digital optical Toslink sources to a single optical TosLink (SPDIF) input on an AV amplifier, Hi-Fi or home cinema system. The optical switch will automatically detect the live signal and switch to this channel.
Ideal for use with games consoles, HD players, set top boxes, PC_s etc. a... Read more
The Lindy 2 Port Automatic Optical Audio Switch allows users to connect two digital optical Toslink sources to a single optical TosLink (SPDIF) input on an AV amplifier, Hi-Fi or home cinema system. The optical switch will automatically detect the live signal and switch to this channel.
Ideal for use with games consoles, HD players, set top boxes, PC_s etc. and saves on wear and tear of constant plugging and unplugging of cables.
Please note: TosLink cables are not included.
Collapse textProduct downloads
Product details
Key features
- Connects two digital optical Toslink sources to a single optical Toslink input
- Automatic or manual switch function
- Input ports: 2 x Toslink (Optical Fibre)
- Output Ports: 1 x Toslink (Optical Fibre)
- 2 year warranty
Specifications
-
AV InterfaceTosLink
-
Supports Bandwidth32 - 96kHz
-
Supported AudioU ncompressed PCM / LPCM, Dolby AC-3, Dolby 5.1, Dolby Digital and DTS
-
Special FeaturesAutomatic switching of active ports
-
Input2 x TosLink (Optical Fibre)
-
Output1 x TosLink (Optical Fibre)
-
Power5.5/2.1mm DC socket
-
Dimensions (approx.) WxDxH75x65x30mm (2.95x2.56x1.18in)
-
Housing MaterialPlastic
-
Net Weight0.055kg (0.12lb)
-
Operating Temperature0°C - 50°C (32°F - 122°F)
-
Storage Temperature-20°C - 70°C (-4°F - 158°F)
-
Humidity20 - 80% RH (non-condensing)
-
Power Requirements5VDC 1.2A
-
ColourBlack
