MGC-3.91-V77 Outdoor LED module for composite screens for rental 3.91 mm pitch 500x500mm
Download product sheetMagic Series: The Modular LED Screen Designed for Rental
The Magic series is the ideal solution for the rental industry, combining advanced technology, reliability, and practicality. Designed for quick and intuitive installation, it optimizes time and reduces operational costs during events.
Crafted with a durable die-cast aluminum structure, the Magic serie... Read more
Magic Series: The Modular LED Screen Designed for Rental
The Magic series is the ideal solution for the rental industry, combining advanced technology, reliability, and practicality. Designed for quick and intuitive installation, it optimizes time and reduces operational costs during events.
Crafted with a durable die-cast aluminum structure, the Magic series features an innovative 125x500 mm tile format that minimizes gaps between modules and reduces the need for connectors, ensuring greater continuity and easier assembly.
Equipped with Nationstar SMD 1921 LEDs, it delivers reliability, long lifespan, and superior visual quality, with vivid and sharp images that enhance every detail. Available in various formats and configurations, with the possibility of curved installations, it is perfect for indoor and outdoor events, meeting the needs of professionals and operators in the rental industry.
Collapse textHighlights
Portability, resistance, and ease of use in one high-performance cabinet solution
Innovative tile design eliminating cross seams and reducing connections
The innovative tile design 500x125mm is meticulously designed to eliminate vertical gaps and significantly minimize the risk of edge bumps, offering a seamless viewing experience. By reducing the number of connectors, our innovative approach ensures enhanced rielability
Equipped with Nationstar LEDs
Nationstar LED combines advanced technology with durability.
Its high contrast ratio, achieved through a black substrate and matte encapsulation, ensures sharp and vivid images. With outstanding reliability, no leakage, and a failure rate below 10 PPM, it delivers consistent performance. The LED offers uniform and accurate colors, natural image quality even at low brightness, and a wide viewing angle of over 120°. Additionally, its design ensures a longer lifespan, making it a reliable choice for any application.
High Refresh rate for reduced flickering
Elevated Contrast & Brightness for outdoor applications
Product details
Key features
- LED Module pitch 3.91mm 500x500mm
- Suitable for outdoor applications
- Equipped with long lasting high quality Nationstar LEDs
- High refresh rate
- Innovative 500x125 mm tile design eliminating cross seams and reducing connections
- 65mm Aluminium frame convenient for storage and transportation
- Protective corners (optional), multi rib reinforced structure, collision resistant pillars
- Zip hole design for quick and easy installation
- Available in curved or bevel edge versions for cube (optional)
Specifications
-
Physical Pitch3.9 mm
-
LED typeNationstar SMD 1921 white
-
Tile Dimension (mm)500 x 125
-
Panel Dimensions (W x H x D) (mm)500x500x65
-
Panel MaterialDie-casting Aluminum
-
No. of tiles per panel (W x H)1x4
-
Physical Resolution of Panel (W x H)128 x 128
-
Weight Per Panel7 kg
-
Weight Per m²24-28 kg/m²
-
Processing16 bit
-
Colors281 trillion
-
Color Temperature6000-10,000 (Adjustable)
-
Contrast Ratio5,000
-
Average/Max Power Consumption80 W/150W per panel
-
Operating and storage Temperature/Humidity-30 to 50℃ / 10% to 90%
-
Brightness4500 nits adjustable 0-100 classes
-
Refresh RateUp to 7680 Hz
-
Viewing Angle H/V160°/140°
-
Expected LED Lifetime (Max)100,000 hours
-
IP RatingFront IP 65, Back IP 54
