NAC3FX-W-TOP powerCON TRUE1 TOP Mains Connector - Female
Download product sheetDirect successor: NAC3F-TRUE1-S
The powerCON TRUE1 TOP is a locking true mains connector. It replaces appliance couplers wherever a very rugged solution in combination with a locking device is needed in order to guarantee a safe power connection.
Keyed for Power IN, screw terminals, up to 16 A (USA: 20A)
The powerCON TRUE1 TOP is a single-phase connector with bre... Read more
Direct successor: NAC3F-TRUE1-S
The powerCON TRUE1 TOP is a locking true mains connector. It replaces appliance couplers wherever a very rugged solution in combination with a locking device is needed in order to guarantee a safe power connection.
Keyed for Power IN, screw terminals, up to 16 A (USA: 20A)
The powerCON TRUE1 TOP is a single-phase connector with breaking capacity (CBC).
Product downloads
Product details
Key features
- IEC EN 60320-1, UL 60320-1 and C22.2 No. 60320-1:19 certified, thus accepted as a component for cord sets acc. to IEC 60799 / UL817 and equipment acc. to IEC 62368-1
- Unique NEUTRIK locking bushing and strain relief for cable diameters 6 mm to 12 mm (0.23 – 0.47 inches)
- Heavy duty sealed power connector for harsh and demanding environment
- Uses high impact UV-resistant materials
- Extremely robust and reliable cable retention
- Lockable, single phase connector with Circuit Breaking Capability (16A resp. 20 A 250 VAC)
- Superior NEUTRIK quality standard
Specifications
-
Connector seriespowerCON TRUE1 TOP
-
Contact resistance≤ 2 mΩ
-
Dielectric strength4 kVdc / 2.8 kVac
-
Insulation resistance> 0,1 GΩ (after damp heat test IEC 68-2-30)
-
Number of electrical contacts2 + PE
-
Rating EuropeEN 60320-1: 16 A 250 V AC
-
Rating USAUL 60320-1 & C22.2 No. 60320-1:19: 20 A 250 V AC
-
Cable O.D.6 - 12 mm (0.23 – 0.47 inches)
-
Lifetime> 5000 mating cycles
-
Wiresize1.0 - 2.5 mm²
-
Wiresize12 AWG
-
Contact plating2 µm Ag
-
ContactsBronze (CuSn0.2)
-
InsertPolyamide (PA 6.6 30 % GR)
-
Locking elementZuAl4Cu1
-
ShellPolyamide (PA 6.6 30 % GR)
-
Strain reliefPolyacetal (POM)
-
FlammabilityUL 94 V-0
-
Temperature range-30 °C to +80 °C
- More Less
