XPRS-152 15” 2-way active loudspeaker

Download product sheet

The XPRS2 Series couples the versatility and mobility of the original XPRS Series with elevated sound-performance and audio intelligibility to deliver a high-caliber speaker system for mobile DJs, live sound, houses of worship, rental and fixed installations.

Buy this product online

Search Google Shopping

Media

(Old ver.) XPRS2 Active Speaker Series Introduction

Highlights

Powerful Class D Amplification

The XPRS2 Series employs Class D Amplification with high output wattage for a powerful and premiere audio experience for performers and listeners alike. The XPRS82 and XPRS152 full-range speakers feature Class D 2000 W amplification, while the XPRS1152ST and XPRS1182ST subwoofers offer Class D 4000 W amplification.

High Quality, Robust Build

Pioneer DJ’s all-new XPRS2 Series features a sleek all-black, protective plywood cabinet for performance in harsh outdoor and indoor environments. The series models all come with a durable handle to support system portability and handling during setup and take down. The XPRS2 Series also features rubber feet to create separation and shock absorption between surfaces.

Four DSP Modes

Both of the XPRS2 full-range speakers contain four different DSP preset modes—Live, Music, Speech and Studio Monitoring—to address the needs of different listening environments.

16 Customizable User DSP Modes

In addition to the four presets, each XPRS2 full-range speaker includes 16 custom user DSP modes - which can be saved with different names - to ensure the EQ settings are maximized for every scenario.

Full-Range Speaker Design

The larger of the new full-range speakers, the XPRS152, features a 15” woofer and 3” voice coil with a 1” exit compression driver and 1.75” voice coil for superb sound coverage across mid to large venues. With a frequency response of 45 Hz – 20 kHz and a maximum SPL of 133 dB, the XPRS152 is ideal for live DJ sets, concerts, and applications in difficult audio environments, such as venues with poor acoustics.

Product details

Specifications

Type

15 inch 2-way active loudspeaker
Amplifier Output

Class D 2000W peak
Power supply

110 V to 240 V (50 Hz/60 Hz)
Power consumption

800 W
Frequency Range

45 - 20000 Hz
DSP modes
Factory Presets (4 types)
Sub Setting (Sub Setting menu is for selecting the high-pass frequency or matching subwoofer)
EQ (4-band equalizer)
User Programs (16 presets)
DSP presets modes

Factory presets
Maximum Sound Pressure

133 dB
Cross Over Frequency 2 kHz
Inputs

MIC / LINE x 1 (Combo), HI-Z / LINE x 1 (Combo), 3.5 mm stereo mini jack x 1 (Unbalanced input)
Outputs

MIX (XLR)
Speaker Driver

15 inch ferrite LF cone driver, 1.75 inch compression driver
Finish

Black paint, Rubber feet
Handle

2 metal handles (on left side and top)
Pole socket

35 mm socket
Rigging point

10x M10
Enclosure Plywood (TSCA)
Amplifier Protection

Thermal limiting, Digital Limiter, Digital compressor
Driver Protection

Short circuit protection
Power unit Protection

Primary AC mains overcurrent protection, Primary AC mains overvoltage protection
Size (WxHxD)

421x726x410 mm
Weight

25.2 kg
Accessories

XPRS152 x 1 (not sold as a pair), Powerd cord, Quick start guide, Important Safety Precautions
