KO102 6x3.15" Compact Passive Line Array/Point Source Speaker 8 Ohm (black color)
Download product sheetKoral-KO102 is a compact column speaker delivering professional performance in visually sensitive environments. Designed for premium AV and residential applications, it combines controlled directivity with a minimal footprint while offering the output of a larger system.
It features 6 x 3" mid-frequency drivers and a dedicated high-frequency unit. A rear swit... Read more
Koral-KO102 is a compact column speaker delivering professional performance in visually sensitive environments. Designed for premium AV and residential applications, it combines controlled directivity with a minimal footprint while offering the output of a larger system.
It features 6 x 3" mid-frequency drivers and a dedicated high-frequency unit. A rear switch selects Pure Array mode for extended throw and linear coherence, or Point Source mode for wider dispersion and flexible mounting. In residential installations, Point Source mode allows use as a centre, left/right or surround speaker, ensuring consistent coverage without compromising interior design.
Collapse textProduct downloads
Media
Highlights
Two Acoustic Identities, One Design
Selectable Line Array and Point Source modes
The point-source behaviour is achieved adopting a dedicated 1.1'' high-frequency transducer that extends the vertical coverage up to 90°, enabling a wider and more focused sound radiation.
Custom Colors and Premium Finishes available upon request
The Koral series is offered in a semi-matte black or an elegant white finish and can be customized to match any RAL code.
Premium brushed or polished stainless steel finishes give the products a chameleon-like ability to reflect surrounding surfaces and blend in with the background.
Also available in 24K gold-plated aluminum (showed in the image) and Rose Gold for the most luxurious finish - ideal for prestigious design projects and upscale applications.
Koral loudspeakers are manufactured to achieve exacting standards and are subject to rigorous quality control system in Italy.
IP54
Product details
Key features
- Switchable Line Array (LA) / Point Source (PS)
- Coverage: 10° V × 90° H in LA mode; 60° V × 90° H in PS mode
- Rated power: 360 W
- In-wall recessed or On-wall mounting versions available
Specifications
-
TypePassive Line Array/Point Source Speaker
-
Transducers6x 3.15'' Neodymium Magnet Woofers + 1.1'' Dome Tweeter
-
Frequency response125 Hz - 20 kHz (-6 dB, with dedicated preset)
-
Max SPL128 dB (peak,calculated using a signal with crest factor 4 (12 dB) measured at 8 m then scaled at 1 m)
-
Power Handling360 W
-
CoverageV. 10° - H. 90° ("LA" mode) | V. 90° - H. 90° ("PS" mode)
-
ConnectorsEuroblock 2,5/ 2-ST-5,08
-
Impedance8 Ω
-
IP RatingIP54
-
Dimensions (WxHxD)950 x 120 x 80 mm (37.4 x 4.7 x 3.1 in.)
-
Weight9,25 kg (20.39 lbs.)
-
MaterialStainless Steel
-
Standard ColorsBlack / White
-
Custom colorsAvailable in any RAL color
-
Premium Metal FinishesAvailable in 24K Gold / Rose Gold / Polished or Brushed Steel
-
Marine-grade TreatmentNot Available
- More Less
