WF-V11PD VHF Plug and Play Wireless Microphone with Bobypack and headset (209.8 MHz)
Download product sheetBuy this product online
-
G. ZECCHINI SRL PIANOFORTI STRUMENTI MUSICALI Available on request
-
STRUMENTI MUSICALI.NET Available on request
-
MUSICALSTORE 2005 Available on request
-
BananaMusic In stock
-
MUSICALSTORE 2005 Available on request
-
End of life
- Contact customer service »
Product downloads
Product details
Key features
- VHF Transmission with SMD Technology
- 4 available Frequencies in VHF Band
- Simple user Interface for plug and play setup
- 30m ideal distance (without obstacles)
- Strong yet lightweight bodypack transmitter
- Professional and Lightweight Headset with high-sensibility dynamic cardioid capsule
Specifications
-
Carrier FrequencyVHF 200 - 215.3 MHz
-
Operating Frequency209.8 MHz
-
Frequency StabilizationAutomatic calibration
-
Dynamic Range> 90dB
-
Total Harmonic Distortion< 0.5%
-
Frequency Response40Hz - 16kHz / ±3dB
-
Packing Dimensions (WxHxD)436 x 104 x 324 mm
-
Packing Gross Weight2.0 kg
-
Receiver Power SupplyDC12V, 500mA
-
Receiver Consumption< 2W
-
Signal/Noise Ratio> 95dB
-
Receiving Sensitivity10dBuV
-
De-Emphasis75uS
-
Audio Output LevelBalanced 400mV; Unbalanced 400mV
-
Receiver Size (WxHxD)211 x 43 x 115 mm (antennas not incl.)
-
Antenna Length110 mm (min.) 430 mm (max.)
-
Net Weight0.295 kg
-
Transmitter Power10mW
-
Modulation TypeFM
-
Deviation37KHz
-
Battery Voltage3V (2x1.5V AA-Type Batteries)
-
Continuous Using7 hours
-
Pocket Trans. Dimensions (WxHxD)62 x 103 x 30 mm
-
Antenna (W/DxH)Ø3 x 9 mm
-
Pocket Transmitter Net Weight0.132 kg (batteries included)
- More Less
