DCR2034-100 Bulk AES/EBU - DMX cable (100 mt)
Download product sheetBuy this product online
-
BananaMusic Available on request
-
STRUMENTI MUSICALI.NET In stock
Product downloads
Product details
Key features
- AES/EBU - DMX cable
- OFC construction (Oxygen Free Copper)
- High conductivity
- Mt: 100
Specifications
-
OFC construction (Oxygen Free Copper)
-
Shielding100% with spiral copper 80x0,10 mm + AL/PT foil + PE filter
-
Inner conductors2x0,34 mm2
-
Copper strand per conductors7x0,25 mm
-
Diameter6,5 mm
-
JacketPVC
-
Temp. range-20(min)/70 (max)
-
AWG24
-
Capac. cond/cond per 1 m<65pF
-
Capac. cond/shield per 1 m115pF
-
Cond. resistance per 1 km53 Ohm
-
Shiedl resistance per 1 km17 Ohm
-
Insulation resist. per 1 km>10G Ohm
-
Surge impedence110 Ohm
- More Less
